Hi-efficiency gearless PM motor traction machines, optimized motor design, high efficiency of power conversion, suitable for light lift car.

Machine-Room-Less, 20% savings in well area. Required top head room and bottom pit depth will be greatly reduced.

Small-diameter sheave, compact structure and reasonable layout

Smooth operation and low noise with composite belts

Environment-friendly and low maintenance

Patent self-owned, CE certified, conform to EN 81-20/50 directive.

We provide perfect elevator solutions for sloping roof building and other distinctive buildings.

Hi-strength TPU cladded cable

Single bending lifetime≥10,000,000 times

Minimum breaking force 43000N

Traction Media Size：31mm Width x 4mm Height

Capacity: 630kgs – 2000kgs

Speed:    0.63 – 2.00m/s

Suspension: 2:1

Input voltage: 3/380v

Max.static load: 5000kgs
